BioMed Black Resin 1 L

RS-F2-BMBL-01

260
excluding VAT

Formlabs is committed to ensuring every medical facility has access to the latest tools to improve care and provide the best patient experience.

BioMed Black Resin is a rigid material with a matte finish for biocompatible applications requiring long-term skin contact or short-term mucosal membrane contact.

Parts printed with BioMed Black Resin are compatible with common solvent disinfection and sterilization methods. BioMed Black Resin is manufactured in our ISO 13485 facility and is also USP Class VI certified which makes it suitable for pharmaceutical and drug delivery applications.

Supports print resolutions: 100 µm and 50µm
Post-curing is required.

  • BioMed Black Resin 1 L
BioMed Black Resin

Why Choose BioMed Black Resin?

Fuel medical innovation using 3D printing and BioMed Black Resin for producing end-use devices where performance and biocompatibility are critical.


Medical-Grade Material
Leverage a material manufactured within our Quality Management System, with strict adherence to ISO 13485.


Excellent Definition
Produce parts and assemblies with complex designs and geometries.


High Contrast
Create contrast between substances or surfaces to aid in visualization with the black, matte finish of BioMed Black Resin.


Biocompatible and Sterilizable Parts
Testing conducted by Formlabs for common use cases is intended to instill confidence that this material is suitable for biocompatible applications.

Applications

Use BioMed Black Resin for producing rigid parts for point-of-care and medical manufacturing applications requiring biocompatibility and matte finish.

Consider BioMed Black Resin for:

Medical devices and device components
Biocompatible molds, jigs, and fixtures
End-use parts requiring patient contact
Consumer goods

*Unlike Formlabs Dental Resins, no intended uses are provided for BioMed Resins. Material properties may vary based on part design, manufacturing practices and other methods. It is the manufacturer’s responsibility and its respective customers and end-users to determine the biocompatibility and performance of all printed parts for their respective application and use. To instill confidence in potential users, Formlabs has tested biocompatibility and sterilization compatibility for common use cases and manufactures BioMed Resins in an ISO 13485 certified facility. We can offer representative examples of what customers have done with our products and the supporting documentation we make freely available.

Material Properties

Post-cured at 70ºC for 60 min

BioMed Black Resin

Ultimate Tensile Strength

35.71 MPa

Tensile Modulus

1523.74 MPa

Elongation

14%

Flexural Strength

57.16 MPa

Flexural Modulus

1668.53 MPa

Hardness Shore D

77 D

Notched Izod

24.77 J/m

Heat Deflection Temp @ 0.45 MPa

67.9ºC

1 Material properties may vary based on part geometry, print orientation, print settings, temperature, and disinfection or sterilization methods used.

2 Data were measured on post-cured samples printed on a Form3B with 100um BioMed Black Resin settings, washed in a Form Wash for 5 minutes in 99% Isopropyl Alcohol, and post-cured at 70°C, 60 minutes in a Form Cure.

3 BioMed Black Resin was tested at NAMSA World Headquarters, OH, USA.

Post-Processing

Form Wash Settings

Duration

5 min in IPA or until clean

Notes

Wash until clean in ≥ 99% IPA. Biocompatible resins must be washed in a dedicated biocompatible IPA bath. They cannot be washed in IPA that is cross-contaminated with other resins.

Form Cure Settings

Duration

60 min



Temperature

70 °C

Notes

Follow the post-curing indications to achieve maximum material properties.
