Why Choose Rigid 4000 Resin?
Rigid 4000 Resin is a glass-filled material that has the highest tensile strength in our Engineering Resin Library.
Stiff
Resistant to deformation under a variety of forces, pressures, and torques.
High Thermal and Chemical Resistance
Withstands high temperatures and a variety of chemicals.
Precise
Produce strong, detailed, and accurate molds or models.
Smooth, Matte Finish
Deliver parts that look and feel like a finished product.
Applications
Produce stiff and strong engineering-grade prototypes that can be load-bearing.
Consider Rigid 4000 Resin for:
Material Properties*
Rigid 4000 Resin
Ultimate Tensile Strength
Tensile Modulus
Elongation
Flexural Modulus
Notched Izod
Heat Deflection Temp. @ 0.45 MPa
Thermal Expansion (0-150 °C)
* Material properties can vary with part geometry, print orientation, print settings, and temperature. Data was obtained from parts printed using Form 3, 100 μm, Rigid settings and post-cured with a Form Cure for 15 minutes at 80 °C.
Post-Processing
Form Wash Settings
15 minutes in IPA
Rigid 4000 Resin contains glass particles, which strengthens printed parts. Maintain separate wash buckets to prevent glass particles adhering to parts printed with other resins.
Form Cure Settings
15 min
80 °C
For parts printed in an engineering-focused resin (such as those in the Rigid, Tough & Durable, and Flexible & Elastic families), post-curing ensures that the parts reach their optimal mechanical properties and can function as designed. There is only one recommended post-curing time for Rigid 4000 Resin V1.
