- Print Technology
- SLA
- Minimum Layer Thickness
- 25 micron
- Categories
- General Purpose
- Colors
- Custom Colors, Matte
Color Kit is the first integrated color mixing solution for resin 3D printing. It enables 3D printing in a range of colors without the manual work of finishing, dying, or painting.
Color Base Resin is the foundation to mix with any Color Kit pigment and create Color Resin. Restock on Color Base Resin to mix with any Color Kit pigment and create Color Resin.
- Print Technology
- SLA
- Minimum Layer Thickness
- 25 micron
- Categories
- General Purpose
- Colors
- Custom Colors, Matte
Select Printer Series and Resin Volume
Bulk Order Discount
- 15%
- 30 L
- 20%
- 60 L
- 25%
- 120 L
- 30%
- 240 L
- 35%
- 1,000 L
- 40%
- 2,000 L
- 45%
- 3,000 L
Accessories
Form 4 Resin Tank
$119
Form 4L Resin Tank
$299
Form 4 Mixer
$50
Form 3 Resin Tank V2.1
$149
Form 3L Resin Tank V3
$299
Compatibility
- Compatible Build Platform
- Form 4 Build Platform, Form 4 Flex Build Platform, Form 3 Build Platform, Form 3 Build Platform 2, Form 3 Stainless Steel Build Platform, Form 3L Build Platform, Form 3L Build Platform 2L, Form 4L Build Platform, Form 4L Flex Build Platform
- Compatible Tank
- Form 4 Resin Tank, Form 2 Resin Tank (PDMS), Form 2 LT Tank, Form 3 Resin Tank V2.1, Form 3L Resin Tank V3
- Compatible Printer
- Form 4, Form 4B, Form 4L, Form 4BL, Form 3, Form 3L, Form 3B, Form 3BL, Form 2
Color Base Resin—
from $79
Why Choose Color Base Resin?
Restock on Color Base Resin to create color models right off the printer with pigments available in Color Kit.
A Perfect Foundation
Pair Color Base Resin and Color Kit to create consistent colors throughout the entire part.
Minimize Waste
Use every bit of Color Pigment by replenishing your Color Base Resin.
Smooth Surface Finish
Print parts that have the polish and finish of a final product.
Applications
Color Base Resin paired with Color Kit is ideal for field testing aesthetic prototypes and concept models.
Concept models, looks-like prototypes
Props and figurines, solid color parts with a matte finish
Material Properties*
| Parameter | Color Base Resin |
|---|---|
|
Ultimate Tensile Strength |
65 MPa |
|
Tensile Modulus |
2.6 GPa |
|
Elongation |
6% |
|
Flexural Modulus |
2.2 GPa |
|
Notched Izod |
25 J/m |
|
Heat Deflection Temp @ 0.45 MPa |
73 ºC |
* Material properties may vary based on part geometry, print orientation, print settings, and temperature. Data was obtained from parts printed using Form 2, 100 μm, Clear settings and post-cured with 1.25 mW/cm³ of 405 nm LED light for 60 minutes at 60°C.
Post-Processing
Washing
The foundational step in any SLA post-processing workflow is to remove any excess resin on the surface of the parts through an alcohol or ether wash.
SETTINGS
Curing
Post-curing for General Purpose Resins is optional. However, Formlabs recommends a short post-curing to reduce surface tack and improve mechanical properties.
SETTINGS
Form Cure V1 | Form Cure V2 | Form Cure L V1 | Form Cure L V2
FAQ
Color Base Resin is the foundational material used with the Color Kit to create custom-colored resin for SLA 3D printing. You mix Color Base Resin with Color Kit pigments to produce Color Resin, which prints parts in a range of colors directly off the printer without the need for painting, dyeing, or manual finishing.
No. Color Base Resin is specifically formulated as a base for mixing with Color Kit pigments. It is not intended to be used on its own and must be paired with Color Kit to achieve the intended color results.
Parts printed with Color Base Resin mixed with Color Kit pigments have a smooth, matte, and opaque finish that reflects the polish and appearance of a final product, eliminating the need for additional painting or post-processing for color.
Color Base Resin has an ultimate tensile strength of 65 MPa, a tensile modulus of 2.6 GPa, a flexural modulus of 2.2 GPa, an elongation of 6%, a notched Izod of 25 J/m, and a heat deflection temperature of 73 degrees C at 0.45 MPa. Note that properties may vary based on part geometry, print orientation, print settings, and temperature. The full Technical Data Sheet is available to download from Formlabs.
Color Base Resin supports a minimum layer thickness of 25 microns.
Color Base Resin paired with Color Kit is ideal for aesthetic prototypes, concept models, looks-like prototypes, props, figurines, and any solid-color parts where a matte finish is desired. It is well suited for field testing and communicating design intent.
Post-processing involves two main steps. First, wash the part using isopropyl alcohol or an ether-based solution to remove uncured resin from the surface. Formlabs Form Wash or Form Wash L are both compatible. Second, post-cure the part using a Form Cure or Form Cure L unit. Post-curing is essential for parts to achieve their full strength and intended functional properties by completing the chemical reaction initiated during printing.
Wash time settings are available on the Formlabs support site for Form Wash and Form Wash L. Cure settings are available separately for Form Cure V1, Form Cure V2, Form Cure L V1, and Form Cure L V2.
Restocking Color Base Resin independently allows you to use every bit of Color Pigment from your Color Kit without waste. Since pigment and base may not be consumed at the same rate, replenishing the base separately keeps your color mixing workflow running efficiently.
Color Base Resin is available starting from a base price that you can confirm on the Formlabs store. Bulk order discounts are available at increasing volume tiers, offering greater savings the more you order. For large volume orders or custom pricing, contact the Formlabs sales team.
