Manufacturing Custom Rollers for Composite Filament Winding

Composite materials like glass fibers and carbon fiber get their high strength and light weight from the way the fiber strands are woven and laid out in the parts, offering unique opportunities to optimize designs based on the stresses engineers expect to affect the components. But working with these custom and non-standardized materials also presents a host of manufacturing challenges.

The University of Sheffield Advanced Manufacturing Research Centre (AMRC) Composites Centre conducts research using cutting edge methods to solve these challenges for high-value industries like aerospace, marine, and automotive

One of the research projects in the facility explores filament winding, that is generally used to produce fuel pipes, tubes, vessels, and shafts for the aerospace and for automotive industries. Working with various materials that have different widths, the researchers had to adapt the system to process the fibers with the high accuracy required in the aerospace industry.

Read on to learn from Alexander Shaw, a composite automation technician working on the project, how the researchers designed and 3D printed different versions of the custom rollers and worked with the AMRC’s open access additive manufacturing station to manufacture the parts in days.

youtube play icon

Watch the video story to look inside the Composites Centre and see how the researchers used the custom rollers for filament winding.

Shaw and the research team worked with the AMRC’s open access additive manufacturing station to manufacture the parts they needed. Read our case study to learn how open access to 3D printing can support hundreds of engineers across the site.

The Unique Challenges of Working With Composites

A filament winding machine works as follows: a spool of fiber goes through a resin bath and then runs through thin rollers to get from the creel at the back of the system to the payout head that is fixed to a 6-axis KUKA robot. The fiber strings then reach a metallic mandrel that is spun like a lathe. As the robot head moves, the fiber is laid down on top of the spinning mandrel.

The fiber strings exit the robot head and reach a metallic mandrel that is spun like a lathe. As the robot head moves, the fiber is laid down on top of the spinning mandrel.

Different fibers can have different material widths or be slightly irregular, which can lead to issues with getting the fiber to process through the rollers. When the researcher switched to a different material that was slightly narrower than what they were using previously, the extra variation in the width required them to manufacture a roller that was slightly smaller than the part that came with the machine originally.

Different rollers are needed for different materials to avoid gaps between the strings and process the fibers with the high accuracy required in the aerospace industry.

“If you've got a narrower toe width than the material you’re running through the rollers, you actually leave gaps in between the toes and it leaves a spread. If these gaps are bigger than about a millimeter, then the parts do not pass aerospace regulations,” Shaw said.

Producing the Parts with Additive Versus Subtractive Tools

To adapt the system to the new materials, Shaw looked at the standard rollers and designed three new versions, all with different diameters and widths depending on the material they were using. For example, for a quarter-inch-wide material, they printed rollers that had a middle section a quarter of an inch wide, and the outside sections of an eighth of an inch, so that when they put two strings together, side by side, there's no gap between the top and bottom creels.

The rollers are assembled with metal bearings that provide low-friction for the system.

The team needed the new rollers as soon as possible to continue with the project and decided that 3D printing would be their best option to produce the parts.

“Machining the new rollers would make the cost much higher and the lead times could potentially be over a week, whereas, with the Formlabs 3D printers, we're able to print something and have it in our hands the same day,” Shaw said.
