Tough 2000 Resin V2
Engineering
SLA
Stiff & Strong
40.4 MPa
1,800 MPa
79 %
Select Printer Series and Resin Volume
| Bulk order quantity (L) | Discount % |
|---|---|
| 1 | 0% |
| 30 | 15% |
| 60 | 20% |
| 120 | 25% |
| 240 | 30% |
| 1,000 | 35% |
| 2,000 | 40% |
| 3,000 | 45% |
Tough 2000 Resin V2 is a rugged material with strength and stiffness comparable to ABS, combining toughness with high temperature and creep resistance.
Tough 2000 Resin V2 excels in heavy-duty applications and delivers highly functional prototypes and end-use parts that resist shattering, deformation, and long-term wear. With a 79% elongation at break and a heat deflection temperature (HDT) of 70 °C, parts maintain structural integrity under mechanical and environmental stress. The new formulation is darker with a matte finish, for presentation-ready parts with enhanced details and a smooth finish.
Tough 2000 Resin V2 is a new material formulation that leverages the technology of Form 4 Series printers to deliver 3x higher fracture toughness, improved temperature resistance, material longevity, and aesthetics compared to the previous version.
Form 4L/BL print settings are in progress, view the settings roadmap to see when settings for this material will be available on the Form 4(B)L.
Tough 2000 Resin V2 has been added to your cart.
Why Choose Tough 2000 Resin V2?
Stiff and sturdy 3D printing material with toughness that rivals ABS.
Tougher Where It Matters
Create sturdy snap-fit assemblies and rugged parts with an elongation at break of 79% and a fracture toughness of 305 J/m2, 3x higher than the previous generation.
Exceptional Creep Resistance
Produce jigs, structural components, and load-bearing parts that resist long-term deformation with only 1.3% creep strain under 4 MPa load after two weeks.
Production-Ready Surface Quality and Fine-Feature Performance
Darker, more matte finish and improved scratch resistance enhance contrast, ideal for prototypes and end-use parts with crisp features and smooth surfaces.
High Environmental Stability for End-Use Applications
A heat deflection temperature (HDT) of 70 °C @ 0.45 MPa ensures reliable performance at elevated temperatures, so that functional parts hold their shape when other plastics may deform.
Applications
Consider using Tough 2000 Resin V2 for:
Mechanical Properties*
| Tough 2000 Resin V2 | ABS, Extruded Sheet, McMaster-Carr | |
|---|---|---|
| Ultimate Tensile Strength | 40.4 MPa | 39 MPa |
| Tensile Modulus | 1800 MPa | 1800 MPa |
| Elongation at Break | 79% | 8% |
| Gardner Impact @ 1/32” (0.8 mm) | 1.6 J | 2.3 J |
| Work of Fracture | 305 J/m2 | 2060 J/m2 |
| Heat Deflection Temp @ 0.45 MPa | 70 °C | Not tested. From literature, ~80-90 ºC |
* Material properties may vary based on part geometry, print orientation, print settings, and temperature. Data was obtained from parts printed using Form 4, 100 μm, Tough 2000 Resin V2 settings and post-cured with a Form Cure V2 for 12 minutes at 70 °C
Formlabs Tough Resins
Next-Generation Tough Resins That Rival Thermoplastics
Compare Formlabs Tough Resins
Tough 2000 Resin V2
Key Characteristics
Strongest and stiffest
Comparable Thermoplastic
ABS
Recommended Applications
Robust jigs, fixtures, protective shells, and snap-fit enclosures
Parts that require high temperature and creep resistance
Tough 1500 Resin V2
Key Characteristics
Balanced blend of stiffness and compliance
Comparable Thermoplastic
PP
Recommended Applications
Parts that need a combination of stiffness and ductility to create compliant mechanisms like latches, flexures, and dampers
Clasps and buckles, self-tapping screw bosses, hinges
Tough 1000 Resin
Key Characteristics
Toughest and most ductile
Comparable Thermoplastic
HDPE
Delrin (POM)
Recommended Applications
Impact-resistant jigs, fixtures, and parts, and squeezable prototypes
Low-friction assemblies, such as gears and ball joints
Post-Processing
Washing
The foundational step in any SLA post-processing workflow is to remove any excess resin on the surface of the parts through an alcohol or ether wash.
For the best surface finish, Formlabs recommends allowing parts printed in Tough 2000 Resin V2 to air dry for at least 10 minutes after washing, before handling.
Curing
Post-curing Engineering and Specialty Resins is essential for parts to achieve their full strength and functionality. This step completes the chemical reaction initiated during printing, transforming the part from its green state into a fully finished component.
