- Print Technology
- SLA
- Categories
- General Purpose
- Applications
- Models & Props, Manufacturing Aids, Rapid Prototyping
- Minimum Layer Thickness
- 100 micron
- Colors
- Custom Colors, Matte
- Flexural Modulus
- 2450.0 MPa
- Tensile Modulus
- 2500.0 MPa
- Notched Izod
- 34.0 J/m
- Heat Deflection Temp. @ 1.8 MPa
- 54.0 °C
- Heat Deflection Temp. @ 0.45 MPa
- 62.0 °C
- Ultimate Tensile Strength
- 54.0 MPa
- Elongation at Break
- 15.0 %
- Flexural Strength
- 91.0 MPa
Color Resin is a General Purpose Resin designed to produce final parts in color without painting, coating, or pigment mixing. Each order is custom-manufactured and quality checked, and ships in as little as two days.
Choose between 16 classic colors or pick a color using our color picker tool to 3D print parts in colors ranging from soft pastels to bold, vivid hues that represent your brand, product line, or creative vision.
Create color-accurate prototypes, color-coded jigs and fixtures, or custom-colored end-use parts with similar dimensional accuracy, aesthetics, and mechanical properties to V5 Formlabs General Purpose Resins.
Note
Color Resin is available exclusively in the USA at this time. Tell us more about your needs for custom-colored 3D printed parts by filling out this short survey.
Need to match a specific color standard?
You can enter a Pantone color code directly in the Contact Sales form below and a member of our sales team will get in touch shortly.
- Print Technology
- SLA
- Categories
- General Purpose
- Applications
- Models & Props, Manufacturing Aids, Rapid Prototyping
- Minimum Layer Thickness
- 100 micron
- Colors
- Custom Colors, Matte
- Flexural Modulus
- 2450.0 MPa
- Tensile Modulus
- 2500.0 MPa
- Notched Izod
- 34.0 J/m
- Heat Deflection Temp. @ 1.8 MPa
- 54.0 °C
- Heat Deflection Temp. @ 0.45 MPa
- 62.0 °C
- Ultimate Tensile Strength
- 54.0 MPa
- Elongation at Break
- 15.0 %
- Flexural Strength
- 91.0 MPa
Bulk Order Discount
- 15%
- 30 L
- 20%
- 60 L
- 25%
- 120 L
- 30%
- 240 L
- 35%
- 1,000 L
- 40%
- 2,000 L
- 45%
- 3,000 L
Accessories
Form 4 Resin Tank
$119
Form 4 Mixer
$50
Form 4L Resin Tank
$299
Form 4L Mixer
$99
Compatibility
- Compatible Build Platform
- Form 4 Build Platform, Form 4 Flex Build Platform, Form 4L Build Platform, Form 4L Flex Build Platform
- Compatible Printer
- Form 4, Form 4B, Form 4L, Form 4BL
Color Resin (Form 4)—
from $99
Why Choose Color Resin V5?
3D print parts in colors that represent your brand, product line, or creative vision with accuracy and consistency. Choose any color to closely match final parts without painting, coating, or pigment mixing.
Note
Color Resin is available exclusively in the USA at this time. Tell us more about your needs for custom-colored 3D printed parts by filling out this short survey.
Rich, Vibrant Colors
3D print parts in a wide variety of colors to match your brand, product line, or creative vision. Make parts that blend in or stand out with the freedom to customize colors from subtle neutrals to bold statement colors.
Accurate, Consistent Color Matching
Print parts in your preferred color for accurate prototypes, functional color-coding, or custom end-use applications. Every order is custom-manufactured and checked for quality, ensuring consistent, repeatable results with every order.
Fast, Easy, Affordable
Make custom-colored parts affordably without long outsourcing lead times or using skilled labor for painting, coating, or pigment mixing. Order as little as one liter, which will be manufactured and shipped within one week, and be ready to 3D print in color right out of the box.
Versatile Mechanical Properties
Use industry-leading materials from Formlabs to create custom-colored 3D printed parts that are both aesthetic and functional. Balance strength, toughness, and stiffness for realistic prototypes, end-use parts, and more.
How To Use Color Resin V5
1. Easy ordering and fast shipping: Order your custom-colored resin on this page. Your colored 3D printing material will be manufactured and shipped within one week from a facility in the USA. When your order arrives, it will be ready to print right out of the box.
2. Custom-generated print settings: Prepare your 3D file for printing using a unique Formlabs Print Setting (FPS) file for optimal print performance. This FPS file can be downloaded through PreForm.
3. Print as normal: Print, wash, and post-cure color 3D printed parts using your usual workflow on Formlabs resin printers, with unmatched reliability and exceptional part quality.
Off-the-shelf part at left, and 3D printed prototype at right.
Applications
Color 3D Printing for Professionals
Realistic prototypes that match the color, material, and finish (CMF) of end-use parts
Color-coded jigs and fixtures
Differentiated parts of an assembly
Custom-colored end-use parts
Material Properties*
| Parameter | Color Resin V5 |
|---|---|
|
Ultimate Tensile Strength |
54 MPa |
|
Tensile Modulus |
2500 MPa |
|
Elongation at Break |
15% |
|
Flexural Strength |
91 MPa |
| Flexural Modulus | 2450 MPa |
|
Notched Izod |
34 J/m |
|
Heat Deflection Temp @ 1.8 MPa |
54 ºC |
|
Heat Deflection Temp @ 0.45 MPa |
62 ºC |
* Data is based on test samples printed in a white colored resin. Properties for other colors will be within ± 15% of this range.
Post-Processing
Washing
The foundational step in any SLA post-processing workflow is to remove any excess resin on the surface of the parts through an alcohol or ether wash.
SETTINGS
Curing
Post-curing for General Purpose Resins is optional. However, Formlabs recommends a short post-curing to reduce surface tack and improve mechanical properties.
SETTINGS
Form Cure V1 | Form Cure V2 | Form Cure L V1 | Form Cure L V2
